CROSSWATER DESIGN THERMOSTATIC 3 WAY SHOWER SPARES

If your Crosswater Design is dripping then you need a new flow cartridge.
Our Compatible X2A071N On Off flow control Cartridge is for the Crosswater Design shower valve DE3000RC and DE3001RC.
On Off cartridge measures 90mm tall. Quarter turn on anticlockwise with 20 teeth.

If your diverter cartridge has failed you can purchase a replacement. This is our SVDIV001.
Supplied without retaining nut collar. Original spare part code X2A044N-1.

If your shower has a problem with the temperature then you need to replace the thermostatic cartridge.
Our SVTHERMSC50 thermostatic valve is compatible with Product code SC50-T20 Thermostatic Cartridge Old Style (Brown)

How do I fit the Crosswater X2A044N-1?
Isolate water supplies before starting.
1. Look for the diverter handle’s grub screw and loosen the said screw.
2. Remove the cover with the retaining nut.
3. Pull out the faulty diverter cartridge.
4. Grease the seals of the replacement Crosswater X2A044N-1. See our SL05-S.
5. Insert the new diverter cartridge in the valve. Make sure the two lugs under the cartridge are introduced in their specific slots to prevent it from shifting.
6. Put in the retaining nut and screw it in place.
7. Return the cover and the handle.

Thermostatic Shower Valve Disassembly and SC50T20 Cartridge Replacement.
Isolate water supplies before starting.
1. Unscrew the valve handle off.
2. Extract the cartridge from the unit using a spanner.
3. Apply silicone grease for plumbing on the replacement SC50T20.
4. Install the cartridge in the valve, calibrate and restore the valve handle.
